| Nominal Voltage | 12.8V |
| Nominal Capacity | 100Ah |
| Minimum Capacity | 98Ah |
| Energy | 1280Wh |
| Cycle Life | >2000 cycles @0.2C 100%DOD |
| Months Self Discharge | <3% |
| Efficiency of Charge | 100% @0.2C |
| Efficiency of Discharge | ~96-99% @0.2C |
| BMS Functions | Over Charge, Over Discharge, Over Current, Short Circuit and Temperature Protection |
| Charge Voltage | 14.6±0.2v |
| Charge Mode | 0.2C to 14.6V, then 14.6V, charge current to 0.02C (CC/CV) |
| Max. Charge Current | 50A |
| Charge Cut-off Voltage | 14.6V±0.2V |
| Max. Discharge Current | 100A |
| Discharge Cut-off Voltage | 10V±0.5V |
| Charge Temperature | 0 °C to 55 °C (32F to 131F) @60±25% Relative Humidity |
| Discharge Temperature | -20 °C to 60 °C (-4F to 140F) @60±25% Relative Humidity |
| Storage Temperature | -20 °C to 45 °C (-4F to 113F) @60±25% Relative Humidity |
| IPS Class | IP65 |
| Case | Plastic |
| Approx. Dimensions | L 330 x W 172 x H 215 mm |
| Approx. Weight | ±10.66KG |
